ABS Flanged Tank Adapters & Outlets
Heavy-Duty Bolted Flanged ABS Fittings for Storage Tank & Vessel Penetrations
Product Overview
Naturegreen Exports Heavy-Duty ABS Flanged Tank Adapters are designed for secure, leak-proof bolted connections on chemical storage tanks, ETP reactor vessels, and pump suction manifolds. Features precision bolt-hole patterns molded from high-tensile ABS-grade ABS.
Key Engineering Features
- Reinforced bolt flange face prevents warping under high bolt torque tightening.
- Standardized 110mm size provides rigid connection to tank wall nozzles and valve flanges.
- 100% chemical corrosion resistance against aggressive wastewater and industrial reagents.
Technical Specifications
| Material Grade | Heavy-Duty ABS-Grade ABS Resin |
|---|---|
| Outer Diameter Size | 110mm Standardized Size (No Custom Sizes) |
| Flange Pattern | ANSI B16.5 / DIN 2501 Standardized Bolt Circle |
| Pressure Rating | PN10 / PN16 Heavy Duty Flange |
| Gasket Seal | Compatible with EPDM, FKM / Viton Gaskets |
| Operating Temp | -40°C to +60°C |
Industrial Applications
Chemical Tank Outlet Nozzles, ETP Lagoon Penetrations, Reactor Tank Connections, Pump Manifold Flanges.
Request Official Engineering Assessment & Quote
